| IMAGE SENSOR |
2.43MP Digital Image Sensor |
| SYSTEM |
PAL |
| LENS |
9-22mm Lens, angle of view- 98.4°-30.2° |
| LENS MOUNT |
M12 |
| SHUTTER TIME |
1/50 ~ 1/10,000 sec |
| SLOW SHUTTER |
Low/Medium/High |
| MINIMUM ILLUMINATION |
Color: 0.01 Lux @F1.2, B/W: 0.001 [email protected] |
| IR RANGE |
72 IR LED, Ø5 mm, 850nm, IR Distance 40-60Mtr. |
| CAMERA PARAMETERS |
Exposure mode, Day/Night level, Auto Iris, Privacy Masking, BLC, AGC, DWDR, White Balance, Mirror, Anti-flicker, Flip, Defog |
| DAY/NIGHT MODE |
Automatic/Color/Black and white |
| PROFILE |
Automatic/Indoor/Outdoor |
| WDR |
Up to 69dB |
| IR CUT |
Automatic /Synchronous |
| SIGNAL/NOISE RATIO |
>60dB |
| VIDEO COMPRESSION |
H.264 |
| VIDEO BIT RATE |
32Kbps~8Mbps |
| AUDIO COMPRESSION |
G.711 |
| AUDIO BIT RATE |
64Kbps |
| DUAL STREAM |
Yes |
| RESOLUTION |
1080P (1920*1080) @25FPS |
| COMMUNICATION INTERFACE |
1 x RJ45, 10/100M adaptive Ethernet interface |
| IMAGE SETTINGS |
Saturation, Brightness, Contrast adjustable by client software or web browser |
| MOTION DETECTION |
Yes |
| PRIVACY MASKING |
Yes, 4 zones |
| REMOTE CONFIGURATION |
Supports Web configuration, Mobile Monitoring and CMS |
| SNAPSHOT CAPTURE |
JPEG |
| ALARM TRIGGER |
Motion Detection, Video Blind, Video loss, Network detection, Storage exception |
| PROTOCOLS |
TCP/IP, HTTP, HTTPS,UDP, RTSP, FTP, PPPOE, DHCP, DDNS, NTP, SMTP,ARSP, UPnP, IPv4,DAS,Cloud, Alarm Server, IP filter |
| SYSTEM COMPATIBILTY |
ONVIF 2.0 |
| MOBILE MONITOR |
Supports iPhone,Android |
| SECURITY |
Multi-level user access with password protection |
| OPERATING CONDITIONS |
Operating Temperature : -10°C ~ 55°C, Humidity 90% or less (non-condensing) |
| POWER RATINGS |
DC 12V ± 10% , Max 3.5W, PoE (802.3af) (only in PoE models) |
| DIMENSION (LxWXH) , WEIGHT |
115mm x 115mm x 85mm , 250g |
